DUAL 16 CHANNEL WIRELESS ​MICROPHONE

Giá: Liên hệ

Mã sản phẩm: TONE 16D
Hãng sản xuất: Sound Barrier/USA
Tình trạng : Còn hàng
Xem sản phẩm từ nhà sản xuất

Views: 104

Rate this product
• UHF Frequency Operation
• 16 Channel Selectable
• PLL Synthesizer Technology
• Dual XLR Output
• 1/4″ Audio Output Jack
• Power, “AF” (Audio) and “RF” (Signal) Front Panel LED Indicators
• Volume, IR Function, and Parameter Front Panel Controls
• Dual Antennas
• DC 5V Power Input Receiver
• Handheld MIC with LED display
The TONE 16 is a 16 channel selectable PLL & UHF microphone that is ultra-light, ultra-compact, and features a front panel LED display that indicates receiver and transmitter information. Front panel controls allow for volume and parameter controls and allow for easy adjustment. The synthesized PLL frequency control circuitry keeps the signal locked and true with dual-tuned molded antennas. The rear panel features balanced XLR and unbalanced 1/4-inch outputs allowing flexible connection options.

Thông số kỹ thuật

Views: 104

Rate this product
Specifications
OPERATING FREQUENCIES:
460-970MHz
MODULATION MODE:
FM
FREQUENCY RESPONSE:
40Hz-17kHz
OPERATING RANGE: 100M (300 FT)
T.H.D.: <1%
NUMBER OF CHANNELS: 16 SELECTABLE
POWER OUTPUT: 10-15dBm
BATTERY TYPE: 2 X AA BATTERY
FREQUENCY RESPONSE: 40Hz-17kHz
DISPLAY TYPE:  LCD / LED
MICROPHONE ELEMENT: DYNAMIC CARDIOID
RECEIVING SYSTEM: PLL SYNTHESIZED
S/N RATIO: 90dB
SENSITIVITY: -90dBm
CHANNEL INTERVAL: 300kHz
OUTPUT IMPEDANCE: 600OHM
DISPLAY TYPE: LCD / LED
ANTENNA TYPE: 2 FLEXIBLE UHF ANTENNAS
OUTPUTS: 2 x XLR & 2 x 1/4″
